memory of the diagnostic interface or in the onboard supply con‐
trol unit. If radio, radio/navigation and telephone units have failed
together, first check fuse of voltage stabiliser.
5.2 Removing and installing voltage stabil‐
iser
Removing
– Push driver's seat as far back as possible.
– Detach Velcro strip of voltage stabiliser - J532- -item 1- from
floor covering.
– Release and pull off connector -2- and remove voltage stabil‐
iser - J532- -item 1- from vehicle.
Installing
Install in the reverse order of removal observing the following:
– During installation, first attach and lock the connector, and
then attach the stabiliser in its original position on the floor
covering by means of the Velcro strip.
up! 2017 ➤ , up! 2020 ➤
Electrical system - Edition 10.2019
34 Rep. gr.27 - Starter, current supply, CCS
