device.
USB memory device requirements: This instrument only supports a USB memory device
with a FAT32 file system. If the USB memory device doesn't work properly, format it into
the FAT32 format and try again; or try another USB memory device.
Updating your instrument firmware is a sensitive
prevent damage to the instrument, do not power off the instrument
or remove the USB memory device during the update process.
To update your instrument firmware, do the following:
(1) Press the Utility key, turn the knob to select [Info]. The Info sub menu is selected.
You can view the model and firmware version.
(2) From a PC, visit www.conrad.de and check if the website offers a newer firmware
version. Download the firmware file. The file name must be ODPFW.upp. Copy the
firmware file onto the root directory of your USB memory device.
(3) Insert the USB memory device into the front-panel USB port on your instrument. If
the status icon appears on the left of the screen, the USB memory device is
installed successfully.
(4) Press the Utility key, turn the knob to select [Info]. Press the ▼ key to select Update
submenu. Press the key.
(5) The instrument displays a message telling you not to remove the USB device or
power off the instrument until the update process is complete. The progress bar of
the screen indicates the update process is in progress.
Note: A firmware update usually takes approximately a minute. Do not remove the
USB memory device during the update process. If you accidentally removed the USB
memory device during the update process, do not power off the instrument. Repeat
the installation process from step 3.
(6) Wait until the instrument displays "Firmware upgrade success.", and then it will
reboot automatically.
Note: If the operation complete message is not displayed, do not power off the
instrument. Repeat the installation process from step 2 using a different type of USB
memory device.
(7) Remove the USB memory device from the front-panel USB connector.
(8) Press the Utility key, turn the knob to select [Info]. The Info sub menu is selected,
view the firmware version. Confirm that the firmware has been updated.
4.9 Port Settings
4.9.1 Serial port
Press the Utility key, turn the knob to select [Port Set]. The Serial sub menu is selected.
