VOLTCRAFT DPPS-16-30 - 18 Technical Data

70
18. TECHNICAL DATA
1086555
(DPPS-16-30)
1086556
(DPPS-32-15)
1086558
(DPPS-60-8)
Operating voltage: 200 – 240 V/AC, 50/60 Hz
Max. input current (230 V/AC): 2.4 A 2.4 A 2.5 A
Maximum output power: 480 W 480 W 480 W
Output voltage: 1 – 16 V/DC 1 – 32 V/DC 1 – 60 V/DC
Output current: 0 – 30 A 0 – 15 A 0 – 8A
Residual ripple at nominal load: 5 mV, 50 mA 5 mV, 20 mA 5 mV, 10 mA
Voltage control response at 10 – 100 %
load change:
50 mV 50 mV 50 mV
Voltage control response at mains
uctuation (170 – 264 V/AC):
20 mV 20 mV 20 mV
Current control response at 10 – 90 % load
change:
150 mA 100 mA 100 mA
Current control response at mains
uctuation (170 – 264 V/AC):
50 mA 50 mA 50 mA
Display accuracy:
±(0.2% +0.3) V/A ±(0.2% +0.3) V/A ±(0.2% +0.3) V/A
OVP switch-off level of the V output:
+2 V (1 – 5 V)
+3 V (5 – 16 V)
+2 V (1 – 5 V)
+3 V (5 – 20 V)
+4V(20 – 32V)
+2 V (1 – 5 V)
+3 V (5 – 20 V)
+4V(20 – 60V)
Degree of effectiveness: 85 % 86 % 87 %
Clock signal: 65 – 85 kHz 75 – 95 kHz 65 – 85 kHz
Performance factor with active PFC: >0.96 >0.96 >0.96
Device fan: Temperature controlled (0 – 100 %)
Mains fuse slow-blow (5 x 20 mm): T3.15AL250V T3.15AL250V T3.15AL250V
Operating temperature: 0 to +40 ºC
Operating humitiy: 10 – 80 %, non-condensing
Storage temperature: -15 to +70 ºC
Storage humidity: 0 – 85 %, non-condensing
Operating altitude: max. 2000 m above mean sea level
Safety class: 1
Approvals: CE EMC: EN 55011, 55012, LVD: EN 60950, 61010
Weight: 2.6 kg
Dimensions (W x H x D): 200 x 90 x 215 mm
