36
b) LCD symbols
No. Symbol Explanation
A Battery capacity
B Automatic power-off is active
C -- Measurement display / Minus sign
D ZERO Zero position
E Automatic range selection is active
F NCV Non-contact AC voltage detection
G HOLD function is active
H Symbol for acoustic continuity check
I Symbol for diode test
J DC Direct current/voltage
K AC Alternating current/voltage
L TRMS True root mean square measurement
M Ω
kΩ,MΩ
Hz
V
mV
A
mA,μA
nF
μF
mF
C
F
Ohm (unit of electric resistance)
Kiloohm (exp.3), Megaohm (exp.6)
Hertz (unit of electric frequency)
Volt (unit of electric voltage)
Millivolt (exp.-3)
Ampere (unit of electric current)
Milliampere (exp.-3), Microampere (exp.-6)
Nanofarad (exp.–9; unit of electrical capacitance)
Microfarad (exp.-6)
Millifarad (exp.-3)
Celsius (unit of temperature)
Fahrenheit (unit of temperature)
