Do not exceed the maximum permitted measuring values.
We recommend beginning the measurement in the largest areas. For this purpose,
place the adjustment wheel “4” at 500 and adjust or correct the measurement size,
downwards, if necessary.
DC
AC
DC
AC
V
• Connect the black measuring line to the COM socket “8” and the red one to the socket V, Ω,
“7”.
For direct current measurements up to 100 mV, use the “DC/AC mA 100 mV” port.
• Set the adjustment wheel “4” to the area for voltage measurement and the slider “5” to “DC,
, Ω”.
