• In order to test the capacity of a battery, connect the black measurement line to the COM
plug “8“ and the red line to the plug “V, Ω.”
• Set adjustment wheel “4” according to the battery type, to
DC
AC
DC
AC
V
1.5 v. or 9 v., and switch “5” to “DC”.
• Place the red measuring tip on the plus pole and the
black measuring tip on the minus pole of the battery.
• The currently measured capacity can be read on the
scale display under the following values
BAT The battery is defective
REPLACE The battery should be exchanged soon
GODD The battery has adequate reserves
