VOLTCRAFT VC920 - V06-09 User Manual

32
INTRODUCTION
Dear Customer,
In purchasing this Voltcraft® product, you have made a very good decision for which we would like to
thank you.
Voltcraft® - In the fi eld of measuring, charging and network technology, this name stands for high-
quality products which perform superbly and which are created by experts whose concern is continuous
innovation.
From the ambitious hobby electronics enthusiast to the professional user, products from the Voltcraft®
brand family provide the optimum solution even for the most demanding tasks. And the remarkable
feature is: we offer you the mature technology and reliable quality of our Voltcraft® products at an almost
unbeatable price-performance ratio. In this way, we aim to establish a long, fruitful and successful co-
operation with our customers.
We wish you a great deal of enjoyment with your new Voltcraft® product!
All names of companies and products are trademarks of the respective owner. All rights
reserved.
89
Test de diode Tension de test max. 2,8 V; courant de test d’env. 1mA 0,0001V
Capacité
40 nF ±(1%+20dgt) ±(1%+10dgt) 0,001 nF
400 nF ±(1%+20dgt) ±(1%+10dgt) 0,01 nF
4 μF ±(1%+20dgt) ±(1%+10dgt) 0,0001 μF
40 μF ±(1%+20dgt) ±(1%+10dgt) 0,001 μF
400 μF ±(1%+20dgt) ±(1%+10dgt) 0,01 μF
4 mF ±(5%+20dgt) ±(5%+10dgt) 0,0001 mF
40 mF Non spécifi é Non spécifi é 0,001 mF
Protection de surcharge : 1 000 V
Fréquence
4 kHz ±(0,1%+8dgt) ±(0,1%+5dgt) 0,0001 kHz
40 kHz ±(0,1%+8dgt) ±(0,1%+5dgt) 0,001 kHz
400 kHz ±(0,1%+8dgt) ±(0,1%+5dgt) 0,01 kHz
4 MHz ±(0,1%+8dgt) ±(0,1%+5dgt) 0,0001 MHz
40 MHz ±(0,1%+8dgt) ±(0,1%+5dgt) 0,001MHz
400 MHz ±(0,1%+8dgt) ±(0,1%+5dgt) 0,01 MHz
Protection de surcharge : 1 000 V
Sensibilité de mesurage : de 10 Hz à 40 MHz : 200 mV / > 40 MHz non spécifi é
Température
-40 bis +40 °C ±(3%+30dgt) ±(3%+10dgt)
0,1 °C +40 bis +400 °C ±(1%+30dgt) ±(1%+1dgt)
+400 bis +1000 °C ±2,5% ±2,5%
Protection de surcharge : 1 000 V
Le capteur de température ci-joint ne peut être utilisé que jusqu’à max. +230 °C !
4-20 mA ±(1%+50dgt) ±(1%+5dgt) 0,01%
Cycle de service 10Hz - 2 KHz
Ne dépassez en aucun cas les grandeurs d‘entrée maximales autorisées.
Ne pas toucher aux circuits ou aux éléments de circuit car ils peuvent avoir des tensions
supérieures à 25 V ACrms ou à 35 V CC ! Danger de mort !
