Oil Filter/By-pass Filter, Change
The oil filter and bypass filter must be replaced at every
oil change.
Remember to hand the old filters in to a re-cycling
station.
WARNING!
Hot oil and hot surfaces can cause burns.
1 Place a collection vessel underneath the filter drip
tray to avoid oil spillage.
2 Clean the filter bracket.
3 Unscrew the bypass filter (1) and the oil filters (2)
with a suitable puller.
4 Check that the mating surfaces on the filter bracket
are clean and that no remains from the old gaskets
are left.
5 Moisten the gaskets on the new filters with engine
oil.
6 Screw on the filter by hand until the rubber gasket
touches the filter bracket mating surface. Then turn
a further 3/4 to 1 turn.
7 Start the engine, run at low idle, and check that no
leakage occurs. Check the oil level after the engine
has stopped.
Switchable oil filters
IMPORTANT:
Even though it is possible, change-over filters must not
be replaced while the engine is running except in an
emergency.
1 Clean the filter holder.
2 Disconnect the filter (1) by turning the handle
clockwise to the end position. Pull down on the knob
below the handle to release the handle.
3 Unscrew the filter and scrap it. Use a filter tool if
necessary.
4 Check that the filter holder sealing surfaces are
clean and that there are no gasket residues left from
the old filter.
5 Lubricate the rubber gasket for the new filter.
6 Screw on the filter by hand until the rubber gasket
just touches the filter holder sealing surface. Then
tighten the filter a further 3/4 to 1 turn.
7 Turn the handle counterclockwise to end position
and replace the right oil filter in the same way.
8 Put the handle in the operating position, straight
down.
9 If necessary, top up the system at the first stop.
Refer to section Engine Oil, Change, page 69.
Maintenance
70 47710406 10-2018 © AB VOLVO PENTA
