D7A T RC Marine Genset
The D7A T RC is an in-line, direct injection, 6-cylinder,
4-stroke marine diesel engine. It has a turbocharger
and is equipped with radiator cooling.
An optimal combination of combustion chambers, fuel
injection system, effective turbocharger and charge air
cooling, provide excellent fuel consumption over the
whole range of power output.
The engine is mounted on a frame with a Stamford
single or double bearing marine generator. Different
starting and control systems are available.
P0013786
1
2
3
4
5
6
7
8
9
10
12
11
14
13
15
16
1 Maintenance indicator air filter
2 Air filter
3 Governor & stop solenoid
4 Oil dip stick
5 Oil cooler
6 Oil filter
7 Fuel filter
8 Freshwater pump
9 Pressure cap exp. tank
10 Air inlet generator
11 Lifting eye
12 Electrical connection unit
13 Air outlet generator
14 Flexible mounting
15 Oil filler
16 Oil drain pump
Maintenance
52 47713337 03-2021 © AB VOLVO PENTA
