Compressor, Cleaning
When using mineral oil as lubricant, soot must be
removed from the compressor and the compressor
housing.
1 Loosen the ventilation pipe (1) from the air intake
(2) and remove the air filter together with the air
intake.
2 Loosen the compressor housing (3) and remove it
carefully.
3 Clean the housing and compressor wheel (4) from
soot using a sharp knife.
NOTICE! Be very careful not to damage anything.
4 Install the compressor house and tighten the
screws equally.
5 Check that the compressor wheel can turn easily; if
not, the housing is not in its right position.
6 Reinstall the air filter together and the air intake.
7 Fit the ventilation pipe to the air intake.
Maintenance
47713337 03-2021 © AB VOLVO PENTA 87
