Volvo EC35 - General View

Presentation
General view 15
General view
Position of the various machine compo-
nents
1 Bucket
2 Bucket cylinder
3 Dipper arm
4 Dipper cylinder
5Boom
6 Boom cylinder
7 Dozer blade cylinder
8 Dozer blade
9 Boom offset cylinder
10 Main chassis
11 Travel system
12 Tracks
13 Upper structure
14 Engine hood
15 Hydraulic system cover
16 Working headlights
