- 103-
monitoring pointer points to the P21.12 bits,
the operation monitoring pointer points to
P21.11 bits
P21.14
Load speed display factor
0.001～65.000
30.000
☆
P21.15
Load speed decimal point
digit
0～3
0
☆
r21.16
Load speed display
Load speed =P27.00*P21.10
Decimal point digit defined by P21.11
-
●
P21.17
Speed display unit
0：0.01Hz；1: 1Rpm
 Display unit for selecting P00.07, r27.00,
r27.01, r10.12
0
★
