- 109-
480V Level:400V～650V
P23.06
Undervoltage fault
detecting time
0.0s～30.0s
1.0s
☆
P23.07
Rapid current limit
0:Disabled
1:Enabled
1
★
P23.10
Over-speed detection
value
0.0%～120.0% maximum frequency
120.0%
☆
P23.11
Over-speed detection time
0.0s～30.0s0.：shielding
1.0s
☆
P23.12
Detection value of too
large speed deviation
0.0%～100.0%(motor rated frequency)
20.0%
☆
P23.13
Detection value of too
large speed deviation
0.0s～30.0s
0.0：shielding
0.0s
☆
P23.14
Input phase loss
detection time
0.0s～30.0s
0.0：forbidden
8.0s
☆
P23.15
Output phase loss
inbalance detecting
0%～100%
30%
☆
P23.18
Fault protection action
selection 1
Unit’s digit : input phase loss
0: coast to stop
1: Emergent stop
2: Stop as per stop mode
3: Continue to Run
Ten’unit: user self-defined fault 1
same as Unit’s digit
Hundred’unit: user self-defined fault 2
same as Unit’digit
Thousand’s unit: communication fault
same as unit’s digit
0000
☆
P23.19
Fault protection action
selection 2
Unit’s digit: motor overload
0: Coast to stop
1: Emergent stop
2: Stop as per stop mode
3: Continue to run
Ten’unit: motor overheat
same as unit’digit
Hundred’unit: too large speed deviation
same as unit’digit
Thousand’s unit: motor over speed
0000
☆
