IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 110 -
same as Unit’digit
P23.20
Fault protection action
selection 3
Unit’s digit: PID feedback lost during running
0: Coast to stop
1: Fast stop
2: Stop as per stop mode
3: Continue to run
Ten’unit: Reserved
same as unit’digit
Hundred’unit: reserved
same as unit’digit
thousand’unit: reserved
same as unit’digit
0000
☆
P23.21
Fault protection action
selection 4
Unit’s digit: output phase loss
0: Coast to stop
1: Fast stop
2: Stop as per stop mode
Ten’unit: EEPROM fault
0: Coast to stop
1: Fast stop
2: Stop as per stop mode
3: Continue to run
Hundred’s unit: PG card fault(reserved)
0: Coast to stop
1: Fast stop
2: Stop as per stop mode
3: Continue to run
Thousand’s unit: off load fault
0: Coast to stop
1: Fast stop
2: Stop as per stop mode
3: Continue to run
0000
☆
P23.24
Fault reset
Define as per bit:
bit0-undervoltage;bit1- inverter overload
bit2-inverter overheat ;bit3-motor overload
bit4-motor overheat;bit5-user’fault 1
bit6- user’fault 2; bit7～15 reserved
0
☆
P23.25
Fault source for auto reset
Define as per bit:
bit0-overcurrent during
acceleration;bit1-overcurrent during deceleration
bit2-overcurrent during constant speed;bit3-over
voltage during acceleration
0
☆
