- 131-
P41.00
Sleep mode and
wake up
selection
Unit’s digit: sleep mode selection
0:no sleep function
1:sleep by frequency
2:AI1 sleep (AI1 as pressure feedback)
3:AI2 sleep(AI2 as pressure feedback)
4:AI3 sleep (AI3 as pressure feedback)
5:AI4 sleep(AI4 as pressure feedback)
Ten’s digit :wake up mode selection
0:wake up by frequency
1:AI1 wake up (AI1 as pressure
feedback)
2:AI2 wake up (AI2 as pressure
feedback)
3:AI3 wake up (AI3 as pressure
feedback)
4:AI4 wake up (AI4 as pressure
feedback)
Hundred’s digit:Sleep wake direction
selection
0: positive direction
Sleep source (AI1 ~ AI4) > P41.03, inverter
will sleep
Wake-up source (AI1 ~ AI4) < P41.04, the
inverter will wake up
1: reverse direction
Sleep source (AI1 ~ AI4) < P41.03, inverter
sleep
Wake-up source (AI1 ~ AI4) > P41.04, the
inverter wakes up.
 When the sleep source and wakeup
source are the same, please pay
attention to the size relationship of
P41.03 and P41.04. If the parameter
setting is unreasonable, when the
wake-up condition is selected, even if
the sleep condition is established, the
00
☆
