IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 132 -
sleep state cannot be entered, and
special attention is required when using.
P41.01
Sleep setting
value by
frequency
0.00Hz～600HZ,It will sleep if value is less
than this value
0.00Hz
☆
P41.02
Wake up
threshold by
frequency
0.00hz～600.00hz, ,It will wake up if value is
bigger than this value
0.00Hz
☆
When selecting frequency sleep and frequency wake-up, it must be set by P41.01 < P41.02. When the frequency
source is PID setting, and the frequency wake-up must be set to PID shutdown operation: P40.39 = 1.
P41.03
Sleep setting
value by
pressure
0～100.0%
0.0%
☆
P41.04
Wake up
threshold by
pressure
0.～100.0%
0.0%
☆
P41.05
Sleep delay time
0.0s～6000.0s
0.0s
☆
P41.06
Wake up delay
up
0.0s～6000.0s
0.0s
☆
P41.07
Sleep
decelerating
time
Setting value decide by P03.16
P03.16 = 2, 0.00～600.00s;
P03.16 = 1, 0.0s～6000.0s;
P03.16 = 0, 0s～60000s
P41.07 set to 0,sleeping stop mode to free
coast。
0.00s
☆
42 Group Simple PLC
r42.00
PLC current
running mode
Read only
-
●
r42.01
PLC current
running
remaining time
Read only
-
●
r42.02
PLC times of
Read only
-
●
