Vortex IR610 Series - Page 143

- 139-
P44.12
Variable selector
3 logic mode
0:>; 1:<; 2:≥;3:≤;4:=; 5:≠; 6:≈
0
☆
P44.13
Variable selector
3 hysteresis
width
0～65535
0
☆
P44.14
Variable selector
4 input
parameter
00.00-98.99(function code index)
00.00
☆
P44.15
Variable selector
4 threshold
00.00-98.99(function code index)
00.00
☆
P44.16
Variable selector
4 logic mode
0:>; 1:<; 2:≥;3:≤;4:=; 5:≠; 6:≈
0
☆
P44.17
Variable selector
4 hysteresis
width
0～65535
0
☆
P44.18
Logic block 1
threshold
parameter 1
00.00-98.99(function code index)
00.00
☆
P44.19
Logic block 1
threshold
parameter 2
00.00-98.99(function code index)
00.00
☆
P44.20
Logic block 1
input source
Unit’digit：parameter 1 bit selection
0-F (Represent 0-15),PP44.18 corresponds
to 0-15 bit
Ten’digit:parameter 2 bit selection
0-F (Represent 0-15),PP44.19 corresponds
to 0-15 bit
0
P44.21
Logic bock 1
function
0:no function;
1:and;
2:or;
3:not and;
4:not or;
5: exclusive OR
6:Ref=1 effective;Ref2=1 ineffective
0
☆
