IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 142 -
to 0-15 bit
Ten’digit:parameter 2 bit selection
0-F (Represent 0-15),PP44.31 corresponds
to 0-15 bit
P44.33
Logic bock 4
function
0:no function;
1:and;
2:or;
3:not and;
4:not or;
5: exclusive OR
6:Ref=1 effective;Ref2=1 ineffective
7:Ref1 up effective,Ref2 up ineffective
8:Ref1 up and signal reverse
9:Ref1 up and output 200ms pulse width
0
☆
P44.34
Constant setting
1
0～65535
0
☆
P44.35
Constant setting
2
0～65535
0
☆
P44.36
Constant setting
3
0～65535
0
☆
P44.37
Constant setting
4
-9999～9999
0
☆
P44.38
Constant setting
1 as per bit
definition
0～65535(define as bit)
0
☆
P44.39
Constant setting
2 as per bit
definition
0～65535(define as bit)
0
☆
P44.40
Constant setting
3 as per bit
definition
0～65535(define as bit)
0
☆
P44.41
Constant setting
4 as per bit
0～65535(define as bit)
0
☆
