Vortex IR610 Series - Page 145

- 141-
7:Ref1 up effective,Ref2 up ineffective
8:Ref1 up and signal reverse
9:Ref1 up and output 200ms pulse width
P44.26
Logic block 3
threshold
parameter 1
00.00-98.99(function code index)
00.00
☆
P44.27
Logic block 3
threshold
parameter2
00.00-98.99(function code index)
0
☆
P44.28
Logic block 3
input source
Unit’digit：parameter 1 bit selection
0-F (Represent 0-15),PP44.26 corresponds
to 0-15 bit
Ten’digit:parameter 2 bit selection
0-F (Represent 0-15),PP44.27 corresponds
to 0-15 bit
0
☆
P44.29
Logic bock 3
function
0:no function;
1:and;
2:or;
3:not and;
4:not or;
5: exclusive OR
6:Ref=1 effective;Ref2=1 ineffective
7:Ref1 up effective,Ref2 up ineffective
8:Ref1 up and signal reverse
9:Ref1 up and output 200ms pulse width
0
☆
P44.30
Logic block 4
threshold
parameter 1
00.00-98.99(function code index)
00.00
☆
P44.31
Logic block 4
threshold
parameter2
00.00-98.99(function code index)
00.00
☆
P44.32
Logic block 4
input source
Unit’digit：parameter 1 bit selection
0-F (Represent 0-15),PP44.30 corresponds
0
☆
