Chapter 6 Fault diagnosis and solutions IR610 high performance vector control frequency inverter user manual
- 152 -
Fault Name
Fault
code
Display
Possible Causes
Solutions
Motor
auto-tuning
fault2
28
Er.tU2
1: The motor parameters are not set
according to the nameplate.
2: The motor auto-tuning times out.
1: Set the motor
parametersaccording to the
nameplateproperly.
2: Check the cable connecting
between the Frequency inverter
and themotor.
Off load
31
Er. LL
1、The frequency inverter running
currentis lower than the setting value.
1、Confirm whether the load is
off
2、Check that the load is
disconnected or the parameter
setting is correct
EEPROM
read- write
fault
32
Er.EEP
1、 Eeprom Operate too frequent
2、 The EEPROM chip is damaged.
1、 Operate Eeprom suitable
2、 Replace the main control
board
Running time arrival
33
Er.TTA
Inverter trial time arrival
1:Contact agent or distributor
485Communication
fault
34
Er.485
1, the work of the host computer is not
normal
2, the communication line is not normal
3, the communication parameter set is
incorrect
1. Check the connection of
upper computer
2. Check the communication
connection line
3. Set communication
parameters correctly
PID feedback
lost during
running
36
Er.FbL
1、 PID feedback<P40.35 setting value
and P40.36 not zero,PID
feedback>P40.37 setting value and
P40.38 not zero
1、 check PID feedback signal
2、 P40.35 and P40.37 set
correct parameter
User-defined
fault 1
37
Er.Ud1
1: The signal of user-defined fault 1 is
input via DI.
2:The signal of user-defined fault 1 is
input via virtual I/O.
1: Reset the operation.
2: Reset the operation
User-defined
fault 2
38
Er.Ud2
1: The signal of user-defined fault 2 is
input via DI.
2:The signal of user-defined fault 2 is
input via virtual I/O.
1: Reset the operation.
2: Reset the operation
The fault code is used for the communication read fault type: when the communication reads the
registers r25.00, r26.00, r26.08, r26.16, the register contents of the reply are fault coded.
6.2 Warning type
The warning is used to remind and inform the user of the current state of the inverter. When the warning
occurs, the keypad will display a warning message, and the warning will automatically reset when the
warning is cleared. Some warnings require the user to check the cause before running the drive, and
some do not care. Warning As an instant reminder, the drive does not store the corresponding
information.
