Pin number diagram
Pin number
Name
Usage
181716151413121110
1 2 3 4 5 6 7 8 9
1，10
PE
Shield terminal
2，11
VCC
Power output for powering the
encoder
5V ± 2%, maximum 200mA
12V±5%, maximum 200mA
3，12
GND
Power supply common terminal
and signal
4
/Z
Encoder Z-signal
5
Z
Encoder Z+signal
6
/B
Encoder B-signal
7
B
Encoder B+signal
8
/A
Encoder A-signal
9
A
Encoder A+signal
13
/W
Encoder
W-signal
Note:UVW is
used to the
synchronous
motor
incremental
encoder, no
need wiring
when it is not
used.
14
W
Encoder
W+signal
15
/V
Encoder
V-signal
16
V
Encoder
V+signal
17
/U
Encoder
U-signal
18
U
Encoder
U+signal
 Open collector type, push-pull output type encoder wiring:
Select the encoder power supply through SW3 on the PG card, SW1 and SW2 to the OC side, as shown
below:：
