VFD300A high performance vector control frequency inverter user manual Chapter 7 Selection guide of inverter Accessory
- 163-
Yellow light (1)
Red light (2)
Yellow light (1) on: indicates normal operation
Yellow light (1) flash: indicates communication
initialization
Red light (2) on: indicates internal communication
failure
Red light (2) flash: indicates CANopen
communication failure or bus off
SW1
DIP switch
Terminating resistor for setting the CANopen bus
Table 7-9 Function description of J1 terminal block
Graphic
name
Description name
Function description
14
CANH
Signal line positive
25
CANL
Signal line negative
3
GND
Signal ground
