IR610 high performance vector control frequency inverter user manual Chapter3 Product appearance and wiring
- 21-
①Unscrew the two screws at the bottom of the cover
②Hold both sides of the cover with both hands and lift
the lower part of the cover
③Push up and lift the entire cover (becareful or you will
snap the keyboard cable )
Installation steps
①Plug in the keyboard line
② buckle the top of the cover
③Tighten the screws at the bottom of the cover
