Chapter3 product appearance and wiring IR610 high performance vector control frequency inverter user manual
- 34 -
Main site
IR610
485+ 485- GND 485+ 485- GND
Slave 1
485
ON
OFF
...
IR610
485+ 485- GND
Slave N
485
ON
OFF
IR610
485+ 485- GND
Slave 2
485
ON
OFF
3-16Multiple inverter RS485 is connected to the host computer for communication
