IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 62 -
Function
code
Parameter name
Description
Default
Property
P03.16 = 0, 0s～60000s
P03.02
Deceleration time 1
Setting value depend on P03.16
P03.16 = 2, 0.00～600.00s;
P03.16 = 1, 0.0s～6000.0s;
P03.16 = 0, 0s～60000s
Depend
on model
☆
P03.03
Acceleration time2
0.01～60000s same as P03.01
Depend
on model
☆
P03.04
Deceleration time2
0.01～60000s same as P03.02
Depend
on model
☆
P03.05
Acceleration time3
0.01～60000s same as P03.01
Depend
on model
☆
P03.06
Deceleration time3
0.01～60000s same as P03.02
Depend
on model
☆
P03.07
Acceleration time4
0.01～60000s same as P03.01
Depend
on model
☆
P03.08
Deceleration time4
0.01～60000s same as P03.02
Depend
on model
☆
The IR610 provides four groups of acceleration and deceleration time. The actual acceleration / deceleration time can be
selected by different methods such as DI terminal, output frequency and PLC running segments. Several methods can not be
used at the same time. Factory default is to use acceleration / deceleration time
1.DI terminal select acceleration and deceleration time of the mapping table is as follows:：
Acceleration and
deceleration time
DI terminal 2
Acceleration and
deceleration time
DI terminal 1
Acceleration and deceleration time
Ineffective
Ineffective
Acceleration and deceleration time
terminal 1（P03.01,P03.02）
Ineffective
Effective
Acceleration and deceleration time
terminal 2（P03.03,P03.04）
Effective
Ineffective
Acceleration and deceleration time
terminal 3（P03.05,P03.06）
Effective
Effective
Acceleration and deceleration time
terminal 4（P03.07,P03.08）
