P04.23
Curve A horizontal
axis 1
0.00V～
P04.25
P04.25
P04.2
6
AI
Correspondin
g setting
P04.2
3
P04.2
4
Note:input less than P04.23,output
decided by curve ten’s digit
0.00V
☆
P04.24
Curve A vertical
axis 1
-100.0%～
100.0%
0.0%
☆
P04.25
Curve A horizontal
axis 2
P04.23～
10.00V
10.00V
☆
P04.26
Curve A vertical
axis 2
-100.0%～
100.0%
100.0%
☆
P04.27
Curve B horizontal
axis 1
0.00V～
P04.29
P04.29
P04.30
AI
Corresponding
setting
P04.27
P04.28
Note:input less than P04.27,output
decide by curve ten’s digit
0.00V
☆
P04.28
Curve B vertical
axis 1
-100.0%～
100.0%
0.0%
☆
P04.29
Curve B horizontal
axis 2
P04.27～
10.00V
10.00V
☆
P04.30
Curve B vertical
axis 2
-100.0%～
100.0%
100.0%
☆
P04.31
Curve C horizontal
axis 1
0.00V～
P04.33
P04.33
P04.34
P04.38
P04.35
AI
Corresponding setting
P04.31
P04.32
P04.36
P04.37
0.00V
☆
P04.32
Curve C vertical
axis 1
-100.0%～
100.0%
0.0%
☆
P04.33
Curve C horizontal
axis 2
P04.31～
P04.35
3.00V
☆
P04.34
Curve C vertical
axis 2
-100.0%～
100.0%
30.0%
☆
P04.35
Curve C horizontal
P04.33～
6.00V
☆
