IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 66 -
Function
code
Parameter name
Description
Default
Property
1：curve B
2：Curve C
3：Curve D
Ten’unit：when input signal lower than minimum input
0：equal to minimum input
1：equal to 0.0%
P04.16
AI3 (option card)
filter time
0.000s～10.000s
0.100s
☆
r04.17
AI3(option card)
actual value
0.00V～10.00V ( it is used to view the port voltage of AI3. When
AI3 is a current type (0~20mA) input, multiplying this value by 2 is
the input current (mA) of the AI3 port.)
-
●
r04.18
AI3(option card)
Conversion value
-100.0%～100.0%(It is used to view the output of the AI3
mapped curve)
-
●
P04.19
AI 4(option card)
Curve setting
Unit’s：AI curve selection
0：curve A
1：curve B
2：Curve C
3：Curve D
Ten’unit：when input signal lower than minimum input
0：equal to minimum input
1：equal to 0.0%
03
★
P04.20
AI4(option card)
filter time
0.000s～10.000s
0.100s
☆
r04.21
AI4(option card)
actual value
0.00V～10.00V ( it is used to view the port voltage of AI4. When
AI4 is a current type (0~20mA) input, multiplying this value by 2 is
the input current (mA) of the AI4 port.)
-
●
r04.22
AI4(option card)
Conversion value
-100.0%～100.0%(It is used to view the output of the AI4
mapped curve)
-
●
