- 65-
Function
code
Parameter name
Description
Default
Property
P04.07
AI 1 Curve setting
Unit’s：AI curve selection
0：curve A
1：curve B
2：Curve C
3：Curve D
Ten’unit：when input signal lower than minimum input
0：equal to minimum input
1：equal to 0.0%
00
★
P04.08
AI1 filter time
0.000s～10.000s
0.100s
☆
r04.09
AI 1 actual value
0.00V～10.00V ( it is used to view the port voltage of AI1. When
AI1 is a current type (0~20mA) input, multiplying this value by 2 is
the input current (mA) of the AI1 port.)
-
●
r04.10
AI 1 Conversion
value
-100.0%～100.0%(It is used to view the output of the AI1
mapped curve)
-
●
P04.11
AI 2 Curve setting
Unit’s：AI curve selection
0：curve A
1：curve B
2：Curve C
3：Curve D
Ten’unit：when input signal lower than minimum input
0：equal to minimum input
1：equal to 0.0%
01
★
P04.12
AI2 filter time
0.000s～10.000s
0.100s
☆
r04.13
AI 2 actual value
0.00V～10.00V ( it is used to view the port voltage of AI2. When
AI2 is a current type (0~20mA) input, multiplying this value by 2 is
the input current (mA) of the AI2 port.)
-
●
r04.14
AI 2 Conversion
value
-100.0%～100.0%(It is used to view the output of the AI2
mapped curve)
-
●
P04.15
AI 3(option card)
Curve setting
Unit’s：AI curve selection
0：curve A
02
★
