The output error of AO1 can be corrected by P05.07 and P05.08, or the mapping relationship between signal
source and actual output can be changed. The formula is:
AO.c = P05.07 + P05.08 × AO.p AO.c: the actual output of AO1;
AO.p: AO1 Value before correction and AO.c, AO.p, 100.0% of P05.07 corresponds to 10V or 20mA.
AO2 output function signal
selection
Same as P05.02 function description
The output error of AO2 can be corrected by P05.11 and P05.12, or the mapping relationship between signal
source and actual output can be changed. The formula is:
AO.c = P05.11 + P05.12 × AO.pAO.c: the actual output of AO2;
AO.p: AO2 value before correction and AO.c, AO.p, 100.0% of P05.11 corresponds to 10V or 20mA.
06 Group Multi-function Digital input
Bit0~Bit8 Correspond to DI1~DI8
Bit12~Bit15 Correspond to VDI1~VDI4
DI1 Numeric input function
0:No function
1:FORWARD
2:Reverse/Forward and reverse switchover
3:Three wire control
4:Forward jog command
5:Reverse jog command
6:Terminal UP
7:Terminal DOWN
8:Clear up UP/DOWN offset
DI2 Numeric input function
DI3 Numeric input function
