IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 72 -
P06.04
DI4 Numeric input function
9：Coast to stop/free stop
10：Fault reset
11：Reverse forbidden
12：Switching run command to Keypad
13：Switching run command to Communication
14：fast stop
15：external stop
16：Switch between motor 1 and motor 2
17：Pause operatoin
18：DC braking
19：Switch between torque and speed Control
20：Torque control diabled
21：Multi-step speed terminal 1
22：Multi-step speed terminal2
23：Multi-step speedterminal3
24：Multi-step speed terminal4
25：Frequency source switchover
26：Switch main frequency source to Numeric
frequency setting
27：Switch main frequency source to AI1
28：Switch main frequency source to AI2
29：Switch main frequency source to AI3
30：Switch main frequency source to AI4
31：Switch main frequency source to
high-frequency pulse input
32：Switch main frequency source to
communication setting
33：Switch auxiliary frequency source to numeric
frequency setting
34：Accel and Decel time terminal 1
10
★
P06.05
DI5(HDI) Numeric input
function
0
★
P06.06
DI6 Numeric input function
（option card）
0
★
P06.07
DI7 Numeric input function
（option card）
0
★
P06.08
DI8 Numeric input function
（option card）
0
★
P06.09
DI9 Numeric input function
（option card）
0
★
P06.13
VDI1 Numeric input
function（Virtual DI）
0
★
P06.14
VDI2 Numeric input
function（Virtual DI）
0
★
P06.15
VDI3 Numeric input
function（Virtual DI）
0
★
