- 73-
P06.16
VDI4 Numeric input
function（Virtual DI）
35：Accel and Decel time termina2
36：Accel and Decel Stop
37：User-defined fault 1
38：User-defined fault 2
39：PID pause
40：PID integral pause
41：PID parameter Switchover
42：PID Positive/negative reaction switch
43：Preset PID terminal 1
44：Preset PID terminal 2
45：PID Main and Auxaliary command switch
46：PID Main and Auxaliary feedback switch
47：Simple PLC status reset
48：Simple PLC time stop
49：Swing frequency stop
50：Counter 1 input
51：Counter 1 reset/clear
52：Counter 2 input
53：Counter 1 reset/clear
54：Clear/reset timed running time
55：Motor 2 Accel and Decel time selection
0
★
P06.17
Virtual input source
Unit’digit: VDI1 input source
0~F: P06.33 specifies the bit0~bit15 of the
parameter
Ten’s digit: VDI2 input source
0~F: P06.34 specifies the bit0~bit15 of the
parameter.
Hundred’s digit: VDI3 input source
0~F: P06.35 specifies the bit0~bit15 of the
parameter
0003
★
