Thousand’s digit: VDI4 input source
0~F: P06.36 specifies the bit0~bit15 of the
parameter
P06.18
DI Forcing function
Define as per bit :Disable;1:Enable
Bit0-bit11:DI1-DI12
Bit12-bit15:VDI1-VDI4
When the bit is enabled, the state of the DI or
VDI is set by the corresponding bit of P06.19.
H0000000
0
L00000000
★
P06.19
DI Forcing data
Define as per bit 0:effective;1:ineffective
Bit0-bit11:DI1-DI12
Bit12-bit15:VDI1-VDI4
0
☆
P06.20
Effective logic of Numeric
input terminal
Define as per bit 0:positive logic;1:negative logic
Bit0-bit11:DI1-DI12
Bit12-bit15:VDI1-VDI4
In the reverse logic, the inactive level of the DI
terminal becomes the active level.
0
★
P06.21
DI1 Effective delay time
0.000s～30.000s
0.000s
☆
P06.22
DI1 ineffective delay time
0.000s～30.000s
0.000s
☆
P06.23
DI2 Effective delay time
0.000s～30.000s
0.000s
☆
P06.24
DI2 ineffective delay time
0.000s～30.000s
0.000s
☆
P06.25
DI3 Effective delay time
0.000s～30.000s
0.000s
☆
P06.26
DI3 ineffective delay time
0.000s～30.000s
0.000s
☆
P06.27
DI4 Effective delay time
0.000s～30.000s
0.000s
☆
P06.28
DI4 ineffective delay time
0.000s～30.000s
0.000s
☆
P06.29
Two wire/3wire operation
control
0：2-wire mode (FWD+REV)1
1：2-wire mode RUN+DIRECTION)2
2：3-wire 1(FWD+REV+ENABLE)
3：3-wire 2 RUN +FWD/REV+ENABLE
0
★
