- 81-
detection amplitude 1
P08.07
Desired frequency
attained2
0.00Hz～maximum frequency(P01.06)
50.00Hz
☆
P08.08
Any frequency reaching
detection amplitude 2
0.0%～100.0% maximum frequency (P01.06)
3.0%
☆
When the output frequency reaches positive or negative detection amplitude of frequency detection value,
DO outputs ON signal. IR610 series inverter provides two parameters of any arrival frequency detection
value, used to set frequency value and frequency detection range.
P08.09
Zero speed detection
amplitude
0.00H～5.00Hz
0.25Hz
☆
P08.10
Zero current detection
level
0.0%～100.0% rated motor current
5.0%
☆
P08.11
Zero current detection
delay time
0.000～30.000s
0.000～30.000s
Notice：When output current≤P08.10 and endure
P08.11 time,corresponding DO output effective
signal
0.100s
☆
When the output current ≤ zero current detection level, lasts for longer than zero current detection delay time,
DO terminal outputs ON signal.
