8” MONITOR REAR SEAT VIDEO HEADREST SYSTEM Owner’s Manual
HR8A
(M1) and (M2) Main Menu
Figure 33
Figure 35
SYSTEM
MENU
BUTTON
OK
BUTTON
UP, DOWN,
LEFT, &
RIGHT
DIRECTION
BUTTONS
SOURCE
BUTTON
HR8A SYSTEM SETUP MENUS
MAIN MENU  System Sources and
Settings
The MAIN MENU is used to access and
change the AV source between USB,
ANDROID, SD Card, AV/DTV, HDMI/MHL,
M1/M2, AUX and GAME (Optional).
SETTINGS is also accessed through the
MAIN MENU. There are three ways to access
the MAIN MENU screen (Figure 33):
• In ANDROID, USB or SD Card mode
touch the SOURCE (S) icon on the
bottom touch screen control bar.
• In AV/DTV, HDMI/MHL, AUX, GAME
and M1/M2 mode tap the screen
twice to access the top Touch Screen
control bar then touch the HOME (
)
icon.
• From the Remote Control press the
SOURCE button (Figure 35).
SETTINGS
The SYSTEM MENU (Figure 34) allows the
user to personalize the HR8A Rear Seat Video
Headrest System settings. The SYSTEM MENU
is used in the initial setup to adjust the picture
quality and customize adjustable functions.
Once the initial settings are customized,
they will remain the same until modi ed
or reset to the factory default settings.
There are three ways to access the SYSTEM
MENU:
• From all sources touch the
SETTINGS (
) icon in the MAIN MENU.
• In AV/DTV, HDMI/MHL, AUX, GAME
and M1/M2 mode tap the screen
twice to access the top Touch
Screen control bar then touch the
SETTINGS (
) icon.
• From the Remote Control press the
SYSTEM MENU button (Figure 35)
The following describes how to adjust and
set settings using the  ve setup screens:
Using the System Menu
Navigating and selecting available settings
in the SYSTEM MENU is accomplished using
the Remote Control buttons (Figure 35) or by
using the touch screen controls.
Follow the steps outlined in the system
Sub-Menus section to select and customize
each of the  ve adjustable Sub-Menu
functions (PICTURE, WFMM, LANGUAGE,
DEFAULT Android and IR TRANSMITTER).
NOTE: The SYSTEM MENU will disappear if
no adjustments are made within 6 seconds.
System Menu
Figure 34
