8” MONITOR REAR SEAT VIDEO HEADREST SYSTEM Owner’s Manual
HR8D
System Sub-Menus
1. Press the SYSTEM MENU button on the
Remote Control (Figure 14) or press the
SOURCE (S) button on the front panel
of the monitor (Figure 15) to display the
SYSTEM MENU.
2. Use the UP and DOWN direction buttons
to select and enter the desired SYSTEM
SUB-MENU:
• PICTURE
• WFMM (Only M1 mode)
• LANGUAGE
• DEFAULT DVD
• IR TRANSMITTER
NOTE: Selected items in the SYSTEM
MENU and the Sub-Menus will be
highlighted in orange.
3. Use the UP, DOWN, LEFT and RIGHT
direction buttons to adjust or select an
item in the Sub-Menu screen and then
press the OK button on the Remote
Control (Figure 14) or press the HOME /
MENU SELECT button (Figure 15).
4. To exit the SYSTEM MENU screen or the
SYSTEM SUBMENU screens and return
to the MAIN MENU at anytime, press the
SOURCE SRC button on the Remote
Control or the SOURCE (S button on the
front panel.
PICTURE CONTROL
Picture Control Menu
PICTURE CONTROL from the Front
Panel
:
1. Press and hold the HOME/ MENU SELECT
button on the front panel of the unit to
show the SYSTEM MENU.
2. Use the UP and DOWN direction buttons
to select PICTURE CONTROL (Figure 16)
and press the HOME / MENU SELECT
button to enter the sub-menu.
3. Use the UP and DOWN direction buttons
to select one of the  ve selections in the
Sub-Menu (Brightness, Contrast, Color,
HR8D SYSTEM SETUP SUBMENUS
Figure 16
Tint and Reset).
4. Use the LEFT and RIGHT direction buttons
to adjust the picture setting levels.
NOTE: Levels are set from “0” to “32” for
Brightness, Contrast and Color. The level
for Tint is set from “-16” to “+16” . There is
no Tint Control in PAL Mode.
5. Select Reset to return the picture setting
controls to the factory default settings.
PICTURE CONTROL from the Remote
Control
:
1. Select “M1” or “M2” on the Remote
Control.
2. Press the SYSTEM MENU or PIX button to
enter PICTURE CONTROL then press the
OK button to enter the sub-menu.
3. Use the UP and DOWN direction buttons
to select one of the  ve selections in the
Sub-Menu (Brightness, Contrast, Color,
Tint and Reset).
4. Use the LEFT and RIGHT direction buttons
to adjust the picture setting levels.
NOTE: Levels are set from “0” to “32” for
Brightness, Contrast and Color. The level
for Tint is set from “-16” to “+16”. There is
no Tint Control in PAL Mode.
5. Select Reset to return the picture setting
controls to the factory default settings.
FM CHANNEL
Wireless FM Modulator (WFMM)
Channel Select from the Front Panel
1. Press and hold the HOME/ MENU SELECT
button on the front panel of the unit to
show the SYSTEM MENU.
2. Use the UP and DOWN direction buttons
to select WFMM (Wireless FM Modulator)
(Figure 17) and press the HOME / MENU
SELECT button to enter the sub-menu.
3. Use the UP, DOWN, LEFT and RIGHT
direction buttons to select the best
channel/frequency from a  ve page list
Figure 17
WFMM Channel/Frequency Menu
