21
Truck (true axle load)
Truck (true axle load) + Trailer
The 9150 will show calculated axle weights
rather than the sum of load cells for each
channel.
The truck can have 2, 3 or 4 axles.
The truck can have 2, 3 or 4 pairs of load cells.
Each load cell in a pair is located at the same
distance from the front of the truck.
If axle group load, instead of individual axle
loads are desired, choose 2 axles instead of
the real number of axles.
Trailer channels weights is the sum of its
inputs (load cells).
During configuration the user will be prompted
for number of axles, number of load cell pairs
and the distance from a common reference
Menu Alarm Net Print
04/07/2011 07:36 AM
Total Gross: lb
42348
Remember....
When ”GENERIC” is
selected no graphic
To Next Page
