24
Tilt Zeroing
Select Tilt Zeroing in the Calibration Wizard.
Make sure the vehicle is as level as possible. This step
is preferably done when calibrating the tare weight with
the truck/trailer on the platform scale.
Each Smart box must be zeroed. Make sure the truck
or trailer that the Smart box is mounted on is level.
Select the Smart box (1, 2, 3 etc.) that should be
zeroed by pressing F3 (Previous) or F4 (Next). Press
F2 (Tilt Zero) to perform the zeroing. A
“waiting” message is display during the few
seconds it takes to zero the Smart box tilt
measuring. If zeroing is correctly performed
the zeroing screen is shown again and next
Smart box to zero can be selected.
Press F1 (Escape) when all Smart boxes are zeroed to
quit the Tilt Zeroing wizard.
.Before you calibrate!
VISHAY
PRECISION
GROUP
SI Onboard 9150
Menu Alarm Net Print
04/07/2011 07:36 AM
Total Gross: 42348 lb
12704 29644
Display
Clock
Langauge
Configure
Calibrate
Alarm
Printer
PIN
Diagnostics
Maintenance
Calibrate
Escape Enter
