VPG SI Onboard 9150 User Manual

31
I/O connection
Output load should be connected to common (0V)
terminal of the I/O terminal block. Note that the outputs
are current limited to 200 mA. If a load with larger
consumptions is to be connected an intermediate relay
must be used.
OUT 1
OUT 2
IN 1
IN 2
0V
P5
1
2
3
4
5
Output current
max 200 mA
