VPG SI Onboard 9150 User Manual

4
1. Meter front panel
The front of the 9150 instrument has four
“soft keys” (F1 – F4), four “arrow keys” and
one On/Off key. All keys are tactile and are
backlit for greater visibility. In the center of
each soft key and arrow key there is an
embossment indicating where to press a
key.
The function of the soft keys is shown at
the bottom of the display close to the
respective key. In the example below are
the texts ‘Menu’, ‘Alarm’, ‘Net’ and ‘Print’.
VISHAY
PRECISION
GROUP
SI Onboard 9150
Menu Alarm Net Print
04/07/2011 07:36 AM
Total Gross: 42348 lb
12704 29644
The display is a high resolution
color display with backlight. The
display and key backlight is
controlled in two intensities to
adapt to different light conditions
in the cab.
