5
“Soft Keys” and their uses
Key F1
Used to access the Meter menu - configuration,
calibration and set-up (If PIN code is enabled the code
will be required before entry to the menu system is
allowed.)
Key F2
Opens the alarm list - showing a list of alarms. If there
are active alarms a red flashing symbol is shown in the
upper left corner of the display. If there are
acknowledged alarms the symbol will be black and
white (not flashing).
Key F3
(Text
‘Gross’ or ‘Net’) is used to switch between
gross and net total. Axle/channel weights are
always gross.
Key F4
Will print Total weight and each axle/channel
weight, together with date and time. The total
weight will be Gross or Net as selected on the
display. This key will not be available or shown
unless print function is configured.
VISHAY
PRECISION
GROUP
SI Onboard 9150
Menu Alarm Net Print
On/
off key
Soft keys
Arrow keys
Soft key text
