SPN SID FMI
Blink
Code
Description
Warning
Light
System
Reaction
Cause Action
705 3
Shorted to
UBATT
ATC WL EAP Disabled
AUX5-Output,
shorted to UB
detection.
• An interruption of the AUX5 Output line was detected.
− Electronic air processing (EAP) function: The AUX5-output could be used for EAP
functionality. See EAP maintenance manual MM-1696 for further instructions.
705 4
Shorted to
Ground
ATC WL EAP Disabled
AUX5-Output,
shorted to GND
detection.
• An interruption of the AUX5 Output line was detected.
− Electronic air processing (EAP) function: The AUX5-output could be used for EAP
functionality. See EAP maintenance manual MM-1696 for further instructions.
705 5 Open Circuit ATC WL EAP Disabled
AUX5-Output, open
circuit detection.
• An interruption of the AUX5 Output line was detected.
− Electronic air processing (EAP) function: The AUX5-output could be used for EAP
functionality. See EAP maintenance manual MM-1696 for further instructions.
706 3
Shorted to
UBATT
ATC WL EAP Disabled
AUX6-Output,
shorted to UB
detection.
• An interruption of the AUX6 Output line was detected.
− Electronic air processing (EAP) function: The AUX6-output could be used for EAP
functionality. See EAP maintenance manual MM-1696 for further instructions.
706 4
Shorted to
Ground
ATC WL EAP Disabled
AUX6-Output,
shorted to GND
detection.
• An interruption of the AUX6 Output line was detected.
− Electronic air processing (EAP) function: The AUX6-output could be used for EAP
functionality. See EAP maintenance manual MM-1696 for further instructions.
706 5 Open Circuit ATC WL EAP Disabled
AUX6-Output, open
circuit detection.
• An interruption of the AUX6 Output line was detected.
− Electronic air processing (EAP) function: The AUX6-output could be used for EAP
functionality. See EAP maintenance manual MM-1696 for further instructions.
802 14 4 8 + 1
Supply
Voltage is too
Low
ABS WL
(while
supply
voltage is
detected
as too low)
ABS Wheel
Disabled
ESC/RSC/ATC/
HSA Disabled
The supply voltage
is temporarily too
low.
• Measure the battery or ignition voltage under load. Verify voltage does not drop below
9v (12v system) or 18v (24v system).
• Verify correct ECU and battery ground (less than 1 ohm)
• Check the vehicle battery and associated components (alternator).
• Check for corroded or damaged wiring between the ECU and voltage supply as well as
ground path.
• Check conditions of fuses.
802 14 5 8 + 5
ECU Central
Ground Open
Circuit
ABS WL
ABS Wheel
Disabled
ESC/RSC/ATC/
HSA Disabled
The ECUs
connection to central
ground has been
interrupted or the
resistance measured
is too high.
• Verify correct ECU central ground (less than 1 ohm resistance).
• Check for corroded, loose or damaged wiring between the ECU and central ground
path.
802 14 7 8 + 3
Internal
Voltage
Supply
ABS WL
ABS Wheel
Disabled
ESC/RSC/ATC/
HSA Disabled
A failure was
detected on the
internal ECU relay 1.
• Measure the battery or ignition voltage supply. Verify voltage is between 9v-16v (12v
system) or 18v-32v (24v system).
• Verify correct ECU and battery ground (less than 1 ohm).
• Check for corroded or damaged wiring between the ECU and voltage supply as well as
ground path.
• If all wiring checks are within specs and if fault repeats and does not clear, this may
indicate the ECU has failed.
803 15 3 8 + 5
All ABVs
Output
Shorted to
UBATT
ABS WL
ESC/RSC/ATC
Disabled
Continuity between
suspect Active
Braking Valve output
and voltage supply
(short circuit) is
detected.
• Verify 7.0-14.0 ohm between ABV supply and ABV common for 12V system (26.3-49.0
ohm for 24V system).
• Check for continuity between suspect ABV ground circuit and voltage supply.
• Check for corroded or damaged wiring between the ECU and ABV.
• Fault may indicate an issue with the BPS in certain vintage ECUs, See SID 55 FMI 3.
