WABCO TAILGUARD - Cable Routing

27
6.5 Cable routing
Thesensorcablesmustnotbelaidloosely,butmustbesecurelyfastenedatshortintervals.Intheabsenceofany
adequatefasteningpossibilities,newfasteningpointshavetobecreated,forexample(asshownhere)byweldingon
roundbarstowhichthecablescanbefastenedwithcableties:
Theplug-incouplingsofthesensorcablesshouldbeinstalledinprotectedareas,forexamplebehindacoverofthe
liftingandtippingmechanismasshownhere:
Installation of the ultrasonic sensors
