WABCO TAILGUARD - Page 29

29
Intheareainfrontoftheliftingandtippingmechanism,thejointsensorcableisroutedtotheElectronicExtension
Modulewiththeaidofcableties.
Thesameappliesforalltheothercables.Theseareusuallyroutedfromtheexitpointinthedriver'scabalongthe
vehicleframetotheECU.
Installation of the ultrasonic sensors
