16 Technical data
100_0102_td_0004.fm 38
16.1.1 Extension cable
Designation Unit AR34/6/042 AR34/6/250
Item no. 5100002161 5100002826
Rated current A 9.00 1.70
Rated voltage V 42 250
Rated frequency Hz 200 200
Rated output kW 0.40 0.40
Phases ~ 3 3
Centrifugal force kN 6.98 6.98
Vibrations rpm 6,000 6,000
Hz 100 100
Centrifugal force max. kN 6.98 6.98
Length mm (in) 244 (9.6) 244 (9.6)
Width mm (in) 151 (5.9) 151 (5.9)
Height mm (in) 134 (5.3) 134 (5.3)
Weight kg (lb) 5.94 (13.1) 5.94 (13.1)
Engine type Induction motor
Class rating lll l
Protection class * IP67 IP67
Storage temperature range °C (°F) -30 – +70
(-22 – +158)
-30 – +70
(-22 – +158)
Operating temperature
range
°C (°F) -10 – +50
(-14 – +122)
-10 – +50
(-14 – +122)
Housing external
temperature
°C (°F) 80 (176) 80 (176)
Sound pressure level L
pA
**
dB(A) < 70 < 70
Standard
EN ISO 11201, EN 12649
*
Only guaranteed with a Wacker Neuson power cable.
**
Measured at distance of 1 m (3.2 ft).
WARNING
Warning about voltage.
Serious injuries from electric shock.
Check power cable and extension cable for signs of damage.
Only use extension cables for which grounded conductors are connected to the plug
and the coupling (only for machines of protection class I + III, see chapter "Technical
data").
