7 Components and operator's controls
100_0201_cp_0006.fm 19
7 Components and operator's controls
7.1 Components
AS30e AS50e/AS60e
7.2 Operator's controls
AS30e AS50e/AS60e
Item Designation Item Designation
1 Rechargeable battery (optional) 5 Parallelogram of oscillating suspension unit
(just AS50e/AS60e)
2 Control handle 6 Crankcase
3 Drive motor
(not visible with AS30e)
7 Ramming system
8 Ramming shoe
4 Vibration damper (just AS30e) 9 Nameplate
Item Designation Item Designation
1 Begin- and safety lever 4 Lock
2 Control handle 5 Central lifting point
3 Handle
