10 Operation and use
100_0201_op_0006.fm 29
10.6.1 Remove the rechargeable battery
1. Wait until the machine has come to a complete standstill.
2. Check that the starter lever is in the OFF position.
3. Push the lock down.
4. Carefully pull the rechargeable battery by the handle to the rear until the detent.
5. Pull out the rechargeable battery by the handle and put down safely.
Item Designation Item Designation
1 Lock 2 Rechargeable battery
