Wacker Neuson BPS Series User Manual

Technical Data
BPS Briggs&Stratton 13.3
Type BPS1030B BPS1030Bw
Material number machine 5100065701 5100065702
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 53 56
Nominal power** [kW] 2,6 2,6
Rated speed [1/min] 3600 3600
Operating temperature range [°C] -15 - +45 -15 - +45
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA [dB(A)] 93 93
Sound power level LWA, measured [dB(A* 104 104
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] 4,6 4,6
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
Type BPS1135B BPS1135Bw
Material number machine 5100065703 5100065704
Material number engine 5100065514 5100065514
Centrifugal force [kN] 11 11
Vibrations [Hz] 98 98
Vibrations [1/min] 5880 5880
Area output* [m2/h] 546 546
Flow [m/min] 26 26
Gradeability [%] 36,4 36,4
Length (drawbar in working position) [mm] 930 930
Width [mm] 350 350
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 61 63
Nominal power** [kW] 2,6 2,6
Rated speed [1/min] 3600 3600
Operating temperature range [°C] -15 - +45 -15 - +45
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA [dB(A)] 93 93
Sound power level LWA, measured [dB(A* 104 104
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] 4,5 4,5
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
[en-US] | Version: 5 | 04/2023 | 5100066824 | BPS1030B, BPS1135B, BPS1340B, BPS1550B, BPS2050B | BPS |
Operator’s Manual 49
13
