Wacker Neuson BPS Series User Manual

Technical Data
Combustion engine 13.4
Type BPS1550B BPS1550Bw
Material number machine 5100066075 5100066076
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA [dB(A)] 95 95
Sound power level LWA, measured [dB(A* 107 107
Sound power level LWA guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 4,1 4,1
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
Type BPS2050B BPS2050Bw
Material number machine 5100066077 5100066078
Material number engine 5100066073 5100066073
Centrifugal force [kN] 20 20
Vibrations [Hz] 98 98
Vibrations [1/min] 5880 5880
Area output* [m2/h] 750 750
Flow [m/min] 25 25
Gradeability [%] 36,4 36,4
Length (drawbar in working position) [mm] 970 970
Width [mm] 500 500
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 94,1 99,5
Nominal power** [kW] 3,6 3,6
Rated speed [1/min] 3600 3600
Operating temperature range [°C] -15 - +45 -15 - +45
Storage temperature range [°C] -15 - +40 -15 - +40
Sound pressure level at operator station LpA [dB(A)] 95 95
Sound power level LWA, measured [dB(A* 107 107
Sound power level LWA guaranteed [dB(A)] 108 108
Vibration total value ahv [m/s2] 4,1 4,1
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
13.4 Combustion engine
Engine manufacturer Briggs & Stratton
Material number engine 5100065514
Engine type XR550
Combustion processes four-stroke
[en-US] | Version: 5 | 04/2023 | 5100066824 | BPS1030B, BPS1135B, BPS1340B, BPS1550B, BPS2050B | BPS |
Operator’s Manual 51
13
