Technical Data
13.1 General instructions
13 Technical Data
13.1 General instructions
Information
For system technical reasons, empty columns can be displayed in the
technical data, and numbers and letters that written in superscript or sub-
script may be displayed incorrectly, e.g:
► Sound power level LWA instead of L
WA
► Sound pressure level LpA instead of L
pA
► Vibration total value ahv instead of a
hv
► Carbon dioxide CO2 instead of CO
2
► Unit m/s2 instead of m/s
2
13.2 Noise and vibration data
The noise and vibration data listed have been determined in accordance
with the following guidelines for the typical machine operating conditions /
special test conditions and using harmonized standards:
• Machinery Directive 2006/42/EC
• Noise Emission Directive 2000/14/EC
During operational use, values may differ depending on the prevailing op-
erating conditions.
Sound pressure level at operator station
• L
pA
was determined according to EN ISO 11201 and EN 500-4.
Guaranteed sound power level
• L
WA
was determined according to EN ISO 3744 and EN 500-4.
Weighted vibration total value hand-arm vibration
• a
hv
was determined according to EN ISO 20643 and EN 500-4.
13.3 BPS Briggs&Stratton
Type BPS1030B BPS1030Bw
Material number machine 5100065701 5100065702
Material number engine 5100065514 5100065514
Centrifugal force [kN] 10 10
Vibrations [Hz] 98 98
Vibrations [1/min] 5880 5880
Area output* [m2/h] 500 500
Flow [m/min] 26 26
Gradeability [%] 36,4 36,4
Length (drawbar in working position) [mm] 930 930
Width [mm] 320 320
48 Operator’s Manual | BPS1030B, BPS1135B, BPS1340B, BPS1550B, BPS2050B | BPS | 5100066824 | 04/2023 |
Version: 5 | [en-US]
