wc_tx000640gb.fm
34
Maintenance CRT 36
4.8 Transporting the Machine
ALWAYS turn the engine off and remove the key from the machine before moving
or transporting machine.
To hoist the trowel:
Attach a sling or chains through the lifting bars (a) on each side of the seat
pedestal.
NOTICE: Make sure the lifting device has enough weight-bearing capacity to lift
machine safely. Refer to section Technical Data.
DO NOT lift the trowel by the guard rings or any part of the trowel other than the
lifting fixture, as the component may fail, causing the trowel to fall, possibly injuring
bystanders.
If equipped with the optional integrated wheel kit (b):
From the rear of machine, use the jack handle to raise the blades off the ground
76-102 mm (3-4 in.). Push the machine using the upper frame.
WARNING
WARNING
